Turning center (X・Z・C)

• Table diameterΦ915mm（Φ800/Φ1000）
  Φ36.02inch（Φ31.50/Φ39.37）
• Max. turning diameterΦ1000㎜/Φ39.37inch
• Max. turning height700㎜/27.56inch
• Max. weight of workpiece1500kg/3300lbs

• Table diameterΦ915mm
  Φ36.02inch
• Max. turning diameterΦ1000mm
  Φ39.37inch
• Max. turning height750mm/550mm
  （660mm/460mm）
  29.53inch/21.65inch
  （25.98inch/18.11inch）
• Max. weight of workpiece1500kg（1000kg）
  3300lbs（2200lbs）

※ Numerals in parentheses"()"above are for APC specifications ( the column, however, is of standard specifications ).


3-axis control CNC turning center

Milling function and table indexing (C axis) function, in addition to turning.

This enables a wide range of machining and centralization of machining processes.

• Table diameterΦ1100mm
  Φ43.31inch
• Max. turning diameterΦ1350mm（Φ1300mm）
  Φ53.15inch（Φ51.18inch）

  ※ Numerals in parentheses"()"above are for APC specifications ( the column, however, is of standard specifications ).
• Max. turning height750mm/550mm
  （565mm/365mm）
  29.53inch/21.65inch
  （22.24inch/14.37inch）

  ※ Numerals in parentheses"()"above are for APC specifications ( the column, however, is of standard specifications ).
• Max. weight of workpiece2000kg（1000kg）
  4400lbs（2200lbs）

  ※ Numerals in parentheses"()"above are for APC specifications ( the column, however, is of standard specifications ).

3-axis control CNC turning center

Milling function and table indexing (C axis) function, in addition to turning.

This enables a wide range of machining and centralization of machining processes.

• Table diameterΦ1250mm（Φ1450mm）
  Φ49.21inch（Φ57.09inch）

  ※ Numerals in parentheses"()"above are for optional specifications.
• Max. turning diameterΦ1600mm(Φ62.99inch)
• Max. turning height1250mm（880mm）
  49.21inch（34.65inch）

  ※ Numerals in parentheses"()"above are for APC specifications ( the column, however, is of standard specifications ).
• Max. weight of workpiece8000kg（4000kg）
  17600lbs（8800lbs）

  ※ Numerals in parentheses"()"above are for APC specifications ( the column, however, is of standard specifications ).

3-axis control CNC turning center

Milling function and table indexing (C axis) function, in addition to turning.

This enables a wide range of machining and centralization of machining processes.

• Table diameterΦ1600mm（Φ1700mm）
  Φ62.99inch（Φ66.93inch）

  ※ Numerals in parentheses"()"above are for optional specifications.
• Max. turning diameterΦ2000mm
  Φ78.74inch
• Max. turning height1600mm（1225mm）
  62.99inch（48.23inch）

  ※ Numerals in parentheses"()"above are for APC specifications ( the column, however, is of standard specifications ).
• Max. weight of workpiece10000kg（5000kg）
  22000lbs（11000lbs）

  ※ Numerals in parentheses"()"above are for APC specifications ( the column, however, is of standard specifications ).

3-axis control CNC turning center

Milling function and table indexing (C axis) function, in addition to turning.

This enables a wide range of machining and centralization of machining processes.

• Table diameterΦ2000mm
  Φ78.74inch
• Max. turning diameterΦ2500mm
  Φ98.43inch
• Max. turning height1815mm（1415mm）
  71.46inch（55.71inch）
• Max. weight of workpiece15000kg（7000kg）
  33000lbs（15400lbs）

※ Numerals in parentheses"()"above are for APC specifications ( the column, however, is of standard specifications ).


3-axis control CNC turning center

Milling function and table indexing (C axis) function, in addition to turning.

This enables a wide range of machining and centralization of machining processes.

• Table diameterΦ2500mm
  Φ98.43inch
• Max. turning diameterΦ3000mm
  Φ118.11inch
• Max. turning height2215mm（1705mm）
  87.21inch（67.13inch）
• Max. weight of workpiece20000kg（9000kg）
  44000lbs（19800lbs）

※ Numerals in parentheses"()"above are for APC specifications ( the column, however, is of standard specifications ).


3-axis control CNC turning center

Milling function and table indexing (C axis) function, in addition to turning.

This enables a wide range of machining and centralization of machining processes.

• Table diameterΦ3000mm
  Φ118.11inch
• Max. turning diameterΦ3500mm
  Φ137.80inch
• Max. turning height2215mm
  87.21inch
• Max. weight of workpiece20000kg
  44000lbs

3-axis control CNC turning center

Milling function and table indexing (C axis) function, in addition to turning.

This enables a wide range of machining and centralization of machining processes.

• Table diameterΦ1100mm（Φ1200mm）
  Φ43.3inch（Φ47.2inch）
• Max. turning diameterΦ1250mm
  Φ49.2inch
• Max. turning height600mm/800mm
  （500mm/700mm）
  23.6inch/31.5inch
  （19.7inch/27.6inch）
• Max. weight of workpiece3000kg
  6600lbs

※ Numerals in parentheses"()"above are for APC specifications.

• Table diameterΦ1600mm
  Φ63.0inch
• Max. turning diameterΦ2000mm
  Φ78.74inch
• Max. turning height1500mm
  59.1lbs
• Max. weight of workpiece8000kg
  17600lbs

• Table diameterΦ2000mm
  Φ78.74inch
• Max. turning diameterΦ2500mm
  Φ98.43inch
• Max. turning height2000mm
  78.74inch（63.0inch）
• Max. weight of workpiece15000kg
  33000lbs

※ Numerals in parentheses"()"above are for APC specifications.

• Table diameterΦ2800mm
  （Φ2400mm･Φ2600mm）
  Φ110.2inch
  （φ94.5inch・φ102.4inch）
• Max. turning diameterΦ3000mm
  Φ118.1inch
• Max. turning height2000mm（1550mm）
  78.7inch（61.0inch）
• Max. weight of workpiece20000kg
  44000lbs

※ Numerals in parentheses"()"above are for APC specifications.

• Table diameterΦ4000mm
  Φ157.5inch
• Max. turning diameterΦ5000mm
  Φ196.9inch
• Max. turning height3000mm〔3500mm〕
  118.1inch（137.8inch）
• Max. weight of workpiece20000kg
  44100lbs

• Table diameterΦ5000mm
  Φ196.9inch
• Max. turning diameterΦ6000mm
  Φ236.2inch
• Max. turning height3000mm〔3500mm〕
  118.1inch（137.8inch）
• Max. weight of workpiece40000kg
  88200lbs

• Table diameterΦ6000mm
  Φ236.2inch
• Max. turning diameterΦ7000mm
  Φ275.6inch
• Max. turning height3000mm〔3500mm〕
  118.1inch（137.8inch）
• Max. weight of workpiece50000kg
  110300lbs

• Table diameterΦ6000mm
  Φ236.22inch

Large-sized vertical lathes, which comprise a system of combined components, offer ideal machine specifications for handling large parts at your company.

Combining components according to target workpieces and working conditions such as table diameter, swing diameter, turning height, table rotation speed, carrying capacity, and tool-slide type configures the ideal cost-effective machine to make your manufacturing line more powerful.
