Drugs and Medicines
Model：VCPC (BALCONY TYPE) Horizontal Cartoning Machine (Intermittent Motion)
A Space Saving Balcony Type Cartoning Machine Developed For Medical & Cosmetics Customers.
1. Able to save the installation space compared to our existing machine.
2. Able to give stable and reliable insertion with Leaflet Servo Inserting System.
3. Able to stably perform the carton pick up, forming, and opening with Carton Opening Device.
4. Universal Design which makes easy operation and maintenance works possible for everyone.
Model：VLP SEAL UNIT
Model：VCPB (BALCONY TYPE) Horizontal Cartoning Machine (Intermittent Motion)
A Compact Cartoning Machine Developed For Medical & Cosmetics Customers.
1. A balcony type frame structure ensures easier maintainance and cleaning works on the lower part of machines.
2. A forced carton opening device, equipped as a standard feature, stabilizes carton pick-up & forming.
Model：VCRC(BALCONY TYPE) Horizontal Cartoning Machine(Continuous Motion)
1. Space saving design fits in only two-thirds of the floor space needed by our conventional cartoners and adapts to a flexible layout.
2. The direct drive system using a servo motor dramatically reduces maintenance works.
3. The ion (C) system + finger (F) holding (H) mechanism ensures reliable opening of cartons.
4. The timing belt in the carton conveyor enables oil-less operation and eliminates stretching defects on the carton finish.
5. All necessary operations are easily performed from the front of the machine.Customer feedback on easy-of-use was given primary importance in the design.
Model：VCRC(BALCONY TYPE) Horizontal Cartoning Machine (Continuous Motion)
Model：VCVD series THE VERTICAL CARTONING MACHINE
Model：VZC52 Vertical Cartoning Machine (Intermittent Motion)
The custom design possible with the VZC type specialized cartoning machine is ideal for a variety of products that could not be handled in the past.
This space-saving vertical cartooning machine is designed to form set-up type cartons and automatically supply products.
Model：VCP-Q Horizontal Cartoning Machine (Intermittent Motion)
Horizontal type intermittent motion cartoning machine suited to high-variety, small to medium lot production. Comes with a Quick Change mechanism to respond to changes in production type.
Two types available with size change mechanism: standard (Q) and economy (QE).
A series lineup that covers packing of relatively small products through to larger sizes suited to volume packaging.
Model：VCR-Q Horizontal Cartoning Machine (Continuous Motion)
1. Equipped with Quick Change Mechanism,Rotary Type Carton Pick-Up Unit, Large Volume Carton Magazine as its standard features, VCR-Q is the state-of-the art horizontal cartoner in every sense of word.
2. All the know-hows established through the overwhelming market share are incorporated into a plentiful of options available too.
Model：VWKD (BALCONY TYPE) Film Over-Wrapping Machine
A film-over wrapping machine which pushes cartons to film supplied from a rolled film, sever the film, and wrap the cartons over with the film after accumulating certain number of cartons.
Model：VCFT Top-Loading Cartoning Machine
A cartoning machine that forms compact cartons from blank sheets, slides them over the packed product from the top surface, and then seals the compact cartons.
An automatic feeder unit that uses various types of robots to supply packed products means various packaging types are possible.
Model：VCPL Horizontal Cartoning Machine (Intermittent Motion)
1. Intermittent motion cartoning machine which can handle large size cartons.
2. Able to make even height-tall cartons finish beautifully.
Model：VCF・VCFE Forming Cartoner
Model：VCL-Q Tray Packer
A tray type packer to pack accumulated products with cardboard blank sheet.
1. The packer is followed by such processes as banding (VWST Tight Packer), Sleeve Wrapping (VWS), Film Over-Wrapping (VWK).
2. The final package can be displayed at retail store shelves after removing the film.
3. Two types of tray package are available; longitudinal and trans-verse orientation.
Model：VCRE (BALCONY TYPE) High-speed Horizontal Cartoning Machine (Continuous Motion)
A high-speed cartoning machine with a balcony type frame structure and loading space on the back side for outstanding maintenance, sanitary and design aspects.
Carton ejection forming forces cartons open with the side-suction type 4-head rotary unit that ensures reliable ejection forming, even under high-speed operation.
Connection with a blister packing unit enables use with a copier for PTP sheet packing.
Model：VCN・VCND Horizontal Cartoning Machine (Continuous Motion)
A cartoning machine having the capabilities of carton pick up, forming, and sealing.
1. VCN & VCND are appropriate for difficultto-load-from-above products (products on the tray and etc.) and for small-to-medium scale production as well as testing purposes.
2. Before closing front-side flap, attendants load products horizontally by hand (VCN) or an automatic feeding devise inserts products horizontally (VCND) into cartons.
Model：VSVB (BALCONY TYPE) Top-Loading Set-Up Caser
A fully automatic corrugated cardboard set-up caser which performs case forming and product-loading on one single machine. Case opens vertically and products are loaded from the top opening. Quick change mechanism featured as the standard assured easier changeover.
Many choices are available for product-loading system; XY robot, vertical multi-joint robot, Mechanical motion, and etc. O-M also has experiences in case dimensions, case geometry other than the below-listed VSVB specifications.
Model：VSHB (BALCONY TYPE) Wrap-Around Caser (Energy Saving Wrap-Around Caser)
This machine is a horizontal-travel, balcony type versatile wrap-around caser.
Adoption of the servo drive system has reduced drive parts, which has improved maintainability and reduced wear parts.
1. Enhanced the energy efficiency by using newly developed electric cylinders which are compact and high performance.
2. The front side uses an open frame structure, which enables enhanced size change workability and improved maintainability in the case forming section.
Model：VSBA Side-Loading Set-Up Caser
Fully automatic corrugated cardboard set-up caser which achieves all processes of case set-up, product loading and case sealing on one machine. For case sealing, two choices are available; hot melt gluing and adhesive tape.
Depending on the size range of case, two model types are available; VSBA-I and VSBA-II.
A quick change mechanism is equipped as a standard feature for easier change-over. Case is opened at its side and products are loaded horizontally.
Model：RD Rotary Die Cutter
Rotary cutters are available in two types: “Crush Die Cutter” and “Rotary Pressure Cutter”.
1. The change from conventional reciprocal motion to rotary motion, the largest advantage of the rotary working system, can drastically improve the efficiency of blanking(pattern) as well as providing high speed, stable, and quiet operation.
2. Conventionally, a cut pattern was made on the rotary cylinder and then the cylinder underwent hardening. Therefore, there was a problem of degraded accuracy caused by distortion during hardening.
O-M’s die cutter uses a method of working a pattern on a high-accuracy rotary cylinder that is hardened and polished in advance by the rotary electric discharge machine(EDM).
This has achieved pattern working that is highly accurate in all three dimensional directions, i.e. height, width, and depth, and enabled high-accuracy edge forming that can withstand long-term use.
